Hakenlift-Abrollkipper
![](/fileadmin/_processed_/6/6/csm_Hakenlift_Fass_3_b992bbb242.jpg)
Tank body HKL
Types | HKL 7500 | HKL 10600 |
---|---|---|
Capacity in l | 7500 | 10,600 |
Approx. length in mm | 4350 | 5350 |
Approx. diameter in mm | 1500 | 1600 |
Hook mounting acc. to DIN (caution with export) | 1.57 m | 1.57 m |
Rear manway ø | 600 mm | 600 mm |
Tank in steel, galvanised | Standard | Standard |
Baffle plate | 1 | 2 |
8000 l compressor with oil drive | Optional | Optional |
Hydraulic turbo filler, for suction | Optional | Optional |
Sprinkler nozzle, 360° hydr. swivelling | Optional | Optional |
Water pump with WB 30 petrol motor, capacity approx. 1100 l/min | Optional | Optional |
Hose reel, 1" x 50 m, with industrial hose and multi-purpose spray lance | Optional | Optional |
Hose reel, 1 1/2" x 20 m, with industrial hose and multi-purpose spray lance | Optional | Optional |
Lockable storage box | Optional | Optional |
Filling pipe, front left, upward into tank with 3" ball valve (required for hydrant filling) | Optional | Optional |
Other lengths and diameters available on request!
